CHOICE OF:
Stainless: ASTM A581/A582 Brass: per ASTM-B16 Aluminum: ASTM B211 Nylon V2: 6/6 UL Rated 94V-2 Phenolic: PBE Grade Natural
Plating: Zinc ASTM B633 Plating: Clear Iridite Finish Nylon V0: 6/6 UL Rated 94V-0 Color Phenolic
FEMALE THREADED STANDOFFS
THREADED STANDOFFS
71
HEX
ROUND
Tel (718) 956-8900
•
Fax (718) 956-9040
(800) 221-5510
•
kec @key elc o.c om
www.ke yelco.com
31-07 20th Road – Astoria, NY 11105-2017
RoHS COMPLIANT
~
ISO 9001 CERTIFIED
®
NOTE: All standoffs over 1.000 (25.4) are tapped .375 (9.5) min. both ends, except 4-40 standoffs which are tapped .250 (6.4) min.
.156
(3.9)
.187
(4.7)
.250
(6.3)
.250
(6.3)
.250
(6.3)
.156
(3.9)
.187
(4.7)
.250
(6.3)
.250
(6.3)
.250
(6.3)
2-56 THREAD
4-40 THREAD
HEX
ROUND
HEX
NYLON V2 NYLON V0 STAINLESS BRASS ALUMINUM BRASS ALUMINUM PHENOLIC
O.D.
CAT. NO. CAT. NO. CAT. NO. CAT. NO. CAT. NO. LENGTH CAT. NO. CAT. NO. CAT. NO.
———1798A 1797A .187 (4.7) 1802A 1801A —
———1798B 1797B .250 (6.4) 1802B 1801B —
———1798C 1797C .312 (7.9) 1802C 1801C —
———1798D 1797D .375 (9.5) 1802D 1801D —
———1450 1891 .250 (6.4) 1547 2025 ——
———1803 1892 .375 (9.5) 1864 2026 —
———1656 1893 .500 (12.7) 1657 2027 —
———1804 1894 .625 (15.9) 1865 2028 —
———1656A 1895 .750 (19.1) 1657A 2029 —
———1805 1896 .875 (22.2) 1866 2030 —
———1656B 1897 1.000 (25.4) 1657B 2031 —
1902A 8440A 1921 1450A 2201 .250 (6.4) 1547A 3478 376
1902B 8440B 1921A 1450B 2202 .375 (9.5) 1547B 3479 377
1902C 8440C 1921B 1450C 2203 .500 (12.7) 1547C 3480 378
1902F 8440D — 1829 1808 .625 (15.9) 1867 1839 —
1902D 8440E 1921C 1450D 2204 .750 (19.1) 1547D 3481 379
1902G 8440F — 1830 1809 .875 (22.2) 1876 1846 —
1902E 8440G 1921D 1450E 2205 1.000 (25.4) 1547E 3482 380
——1921E 1831 2206 1.500 (38.1) 1877 3483 381
——1921F 1832 2207 2.000 (50.8) 1878 3484 382
1903A 8441A 1922 1451A 2208 .250 (6.4) 1548A 3485 383
1903B 8441B 1922A 1451B 2209 .375 (9.5) 1548B 3486 384
1903C 8441C 1922B 1451C 2210 .500 (12.7) 1548C 3487 385
1903F 8441D — 1451D 1813 .625 (15.9) 1548D 1847 —
1903D 8441E 1922C 1451E 2211 .750 (19.1) 1548E 3488 386
1903G 8441F — 1833 1816 .875 (22.2) 1879 1848 —
1903E 8441G 1922D 1635 2212 1.000 (25.4) 1548F 3489 387
——— 1636 1818 1.250 (31.8) 1881 1853 —
——1922E 1637 2213 1.500 (38.1) 1882 3490 388
———1638 1819 1.750 (44.5) 1883 1855 —
——1922F 1639 2214 2.000 (50.8) 1884 3491 389
——— 1642 1820 2.250 (57.2) 1885 1856 —
——— 1643 1825 2.500 (63.5) 1886 1857 —
1904A 8442A 1923 1474A 2215 .250 (6.4) 1692A 3492 390
1904B 8442B 1923A 1474B 2216 .375 (9.5) 1692B 3493 391
1904C 8442C 1923B 1474C 2217 .500 (12.7) 1692C 3494 392
1904F 8442D — 1834 1827 .625 (15.9) 1887 1858 —
1904D 8442E 1923C 1474D 2218 .750 (19.1) 1692D 3495 393
1904G 8442F — 1836 1828 .875 (22.2) 1888 1859 —
1904E 8442G 1923D 1474E 2219 1.000 (25.4) 1692E 3496 394
——1923E 1837 2220 1.500 (38.1) 1889 3497 395
——1923F 1838 2221 2.000 (50.8) 1899 3498 396
——1475A 1822A 1821A .375 (9.5) 3499A 3500A 468
——1475B 1822B 1821B .500 (12.7) 3499B 3500B 469
——1475C 1822C 1821C .625 (15.9) 3499C 3500C —
——1475D 1822D 1821D .750 (19.1) 3499D 3500D 470
——1475F 1822F 1821F 1.000 (25.4) 3499F 3500F 471
6-32 THREAD
8-32 THREAD
.312
(7.9)
.312
(7.9)
10-32 THREAD
