- Compatible with IEEE802.1x/EAP authentication protocol
with combination of RADIUS (authentication) server
- Multiple SSID and 802.1Q tagged VLAN compatible
- Comes with wall mount and ceiling mount screws
- 3 years warranty
Features
WAPS-APG600H
Simultaneous 11n/a & 11n/g/b Business Class Wireless LAN Access Point
Simultaneous 11n/a and 11n/g/b wireless connections
- Simultaneous 11n/a and 11n/g/b wireless connections
- 802.3af compliant PoE unit compatible
- 1000BASE-T Gigabit ethernet port
- Energy efficient features such as intelligent power control
and LED on/off feature
AirStation Pro™ WAPS-APG600H offers high-speed 11n wireless network and
Gigabit wired network experience that is ideal for large network traffic environment
such as offices and educational facilities. With features such as 11n/a & 11n/g/b
simultaneous wireless connections, 802.3af PoE unit compatibility, energy
efficient features, multiple SSID functionality, and various installation options,
the WAPS-APG600H support users looking for speed, functionality and efficiency.
The WAPS-APG600H has two 1000BASE-T LAN ports, capable of transferring data
through the wired LAN network with speed up to 1Gbps. This allows fast data
communication between Gigabit-enabled device throughout your office.
Ideal for offices which requires multiple PC access and large file transfers,
the WAPS-APG600H can output both 11n/a and 11n/g/b signal simultaneously with
speed up to 300Mbps per wireless standard*.
*Based on 40Mhz channel bandwidth mode. Performance may vary depending on user environment.
Compliant with IEEE802.3af Power over Ethernet, the WAPS-APG600H
can be powered with 802.3af PoE unit. If you have an existing 802.3af PoE
unit, it is possible to replace your existing wireless access point with the
WAPS-APG600H, reducing both the cost and hassle.
802.3af compliant PoE unit compatible
In order to provide stable network environment, reliability of network
device is a key factor. Buffalo's original corporate model quality standard
requires selection of highly reliable parts and strict product development,
pursuing for product's durability and longevity. As a result, Buffalo is able
to provide 3 years warranty on this WAPS-APG600H.
Provides 3 years warranty
1000BASE-T port maximize 11n advantage
Parts selected under
strict quality standard
Original board designed
from Buffalo’s Japanese
corporate model standard
Widely available compatible products
Simultaneous Connection
Devices
Devices
PC TV
PC Smart devices Printers
Both 11n/a and 11/n/g/b devices can coexist
Strong against signal congestion
Replace existing
access point
Existing PoE
unit
LAN cable Existing
access point
Specifi cations
Standard Compliance IEEE802.11n, IEEE802.11a, IEEE802.11g, IEEE802.11b
Frequency Range Simultaneous dual band 2.4GHz / 5 GHz
152 x 182 x 35 mm
440 g
Max 7.2 W (AC)
Max 6.72 W (PoE)
Windows® 8 (32/64-bit), Windows® 7 (32/64-bit), Windows Vista® (32/64-bit), Windows® XP
Mac OS® X
Standard Compliance IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x Flow Control,
IEEE802.1D Spanning Tree Protocol, IEEE802.1Q VLAN Tagging
Speed and Flow Control 10/100/1000 Mbps
Number of LAN Ports 2 x RJ-45 (1 port PoE, supports 802.3af)
Wireless LAN Interface
Others
LAN Interface
WAPS-APG600H
AC Adapter
Mounting Kit
User Manual
Warranty Statement
Dimensions (W x H x D )
Weight
Power Consumption
Client OS Support
Box Contents
Simultaneous 11n/a & 11n/g/b Business Class Wireless LAN Access Point
WAPS-APG600H
Infrastructure ModeAccess Mode
2 x 2Antenna (Tx x Rx)
WPA - PSK (AES, TKIP), WPA2-PSK (AES, TKIP), 128/64-bit WEPWireless Security
External AC 100-240V input, 12V DC Output or IEEE 802.3af PoE
Power Supply
Standard Compliance USB 2.0
Connector Type A type
Number of Ports 2
USB Interface
Data Transfer Rates Max 480 Mbps
Power
connector
Power button
LAN port USB port
RJ-45 serial console port
(for future use)
Reset button
AOSS/WPS button
Antennas
moc.aisa-olaffub.wwwOLAFFUB tuobA
BUFFALO Inc., based in Nagoya, Japan, is a leading global provider of award-winning networking, storage and multi-media
solutions for the home and small business environments as well as for system builders and integrators. With three decades of
networking and computer peripheral experience, BUFFALO has proven its commitment to delivering innovative, best-of-breed
solutions that have put the company at the forefront of infrastructure technology.
